switch module 1xN MxN(M≤8、N≤72)
Name:

1xN MxN Switch module 1x5 1x7 4x4..

Class:
Fiber Optical Switches
Type:
Switch module MxN(M≤8、N≤72)

switch module 1xN MxN(M≤8、N≤72) Specification

Click here to View Formal Price(424 pcs are paid)

Fiberer - Company  Profile-2010

Features

  Applications
  • Up to 128 Channels
  • Low Loss, High Reliability
  • Parallel interface (TTL)
  • Modularizing Design

  • Multi-monitoring in Optical
  • Auto-Switching of LAN multi-laser source /detector and multi-sensing
    dynamic monitoring system
  • Testing of fiber, optical Component, network or field projects in
    optical system
 MxN Switch module 1x5 1x7...

Fiberer’ Optical switch is a kind of device ,with the ability of the optical channels’ switching. Among optic fiber transmission system, it is used in optical channels’ control, LAN, light source / detector change, and protect change of network etc.. Test system in optical fiber, it is used in optical fiber and optical fiber device test, network test, open-air optical cable test and optical fiber sensing.

Performance Specifications

Type
Fiberer-M×N
Wavelength Range
530~1625nm
Insertion Loss
≤1.2dB(with optical linker)
Return Loss
SM≥55dB;MM≥25dB(with FC/PC linker)
Cross-Talk
≤-60dB
PDL
≤0.05dB
Wavelength Relative loss Loss
≤0.25dB
Repeatability
≤±0.02dB
Switching Time
≤10ms(Switching to next channel)
Operating life
﹥107 time
Transmission Power
≤500mw
Operation Temp
-5 ~ 55 °C
Storage Temp
-20~+70°C
Power
+5V



OS

wavelength
Port
Type
Modul /IU
Fiber Length
In/Out Connector
85=850nm
13=1310nm
15=1550nm
sp=special
M×N:number of optical channel

S=SM
M=MM

M=modul
U=IU
1=0.5M
2=1.0M
3=1.5M
0=None
1=FC/APC
2=FC/PC
3=SC/APC
4=SC/PC
5=ST
6=LC

Download product datasheet

Download User Guide Content

4×4 switch Download product datasheet







Packaging & Labeling
To protect each of product, Fiberer will use firm and secure Package, and common use Fiberer Label if customer not remark.
It is available to use custmized labeling and packaging for customer request.

Shipment
All shipment will be succssful to arrive customer's address. Fiberer try our best to let the shipment fast for customers, and the common express is by air of Fedex, DHL, UPS, EMS and TNT.
If the customer pay Fiberer the shipment charge, it will use Fiberer express account for the shipment, otherwise it need to use the customer's express account.

Customized & OEM
Fiberer always do Customized for customer's request successfully, It is available for Customized & OEM.

Order Now:
 switch module 1xN MxN(M≤8、N≤72)   (424 pcs are paid)

**Please click 'getOrder' or 'AddToCart' button to get the order(invoice) document directly.
**Shipment charge and lead time will be signed clearly in the invoice after finishing the order.
Quality Assurance:  assure 100% best quality.
(Fiberer assure 100% best quality.the term will be signed on order and invoice,match the safety of international business law.)    Customer Reviews

Description Please Select: Formal Price Qty. AddToCart
Switch module 1x5 850nm±30nm, Multi mode
Weight: 0.2 kg/pcs
Delivery: within 1 week


Pigtail Style:

Fiber Type:

Fiber Length:

InOut Connector:
Part Number (P/N) and Remark

100 pcs, Apply for VIP
10 pcs, USD 555/pcs.
1 pcs, USD 572/pcs.
FOB ShenZhen

Switch module 1x5 1310nm±30nm, Single mode
Weight: 0.2 kg/pcs
Delivery: within 1 week


Pigtail Style:

Fiber Type:

Fiber Length:

InOut Connector:
Part Number (P/N) and Remark

100 pcs, Apply for VIP
10 pcs, USD 555/pcs.
1 pcs, USD 572/pcs.
FOB ShenZhen

Switch module 1x5 1550nm±30nm, Single mode
Weight: 0.2 kg/pcs
Delivery: within 1 week


Pigtail Style:

Fiber Type:

Fiber Length:

InOut Connector:
Part Number (P/N) and Remark

100 pcs, Apply for VIP
10 pcs, USD 555/pcs.
1 pcs, USD 572/pcs.
FOB ShenZhen

Switch module 1x7 850nm±30nm, Multi mode
Weight: 0.2 kg/pcs
Delivery: within 1 week


Pigtail Style:

Fiber Type:

Fiber Length:

InOut Connector:
Part Number (P/N) and Remark

100 pcs, Apply for VIP
10 pcs, USD 785/pcs.
1 pcs, USD 800/pcs.
FOB ShenZhen

Switch module 1x7 1310nm±30nm, Single mode
Weight: 0.2 kg/pcs
Delivery: within 1 week


Pigtail Style:

Fiber Type:

Fiber Length:

InOut Connector:
Part Number (P/N) and Remark

100 pcs, Apply for VIP
10 pcs, USD 785/pcs.
1 pcs, USD 800/pcs.
FOB ShenZhen

Switch module 1x7 1550nm±30nm, Single mode
Weight: 0.2 kg/pcs
Delivery: within 1 week


Pigtail Style:

Fiber Type:

Fiber Length:

InOut Connector:
Part Number (P/N) and Remark

100 pcs, Apply for VIP
10 pcs, USD 785/pcs.
1 pcs, USD 800/pcs.
FOB ShenZhen

Switch module 4x4 850nm±30nm, Multi mode
Weight: 0.2 kg/pcs
Delivery: within 1 week


Pigtail Style:

Fiber Type:

Fiber Length:

InOut Connector:
Part Number (P/N) and Remark

100 pcs, Apply for VIP
10 pcs, USD 1750/pcs.
1 pcs, USD 1850/pcs.
FOB ShenZhen

Switch module 4x4 1310nm±30nm, Single mode
Weight: 0.2 kg/pcs
Delivery: within 1 week


Pigtail Style:

Fiber Type:

Fiber Length:

InOut Connector:
Part Number (P/N) and Remark

100 pcs, Apply for VIP
10 pcs, USD 1750/pcs.
1 pcs, USD 1850/pcs.
FOB ShenZhen

Switch module 4x4 1550nm±30nm, Single mode
Weight: 0.2 kg/pcs
Delivery: within 1 week


Pigtail Style:

Fiber Type:

Fiber Length:

InOut Connector:
Part Number (P/N) and Remark

100 pcs, Apply for VIP
10 pcs, USD 1750/pcs.
1 pcs, USD 1850/pcs.
FOB ShenZhen

Add 19' Rack (1U)
Weight: 1 kg/pcs
Delivery: within 1 weeks


Part Number (P/N) and Remark

100 pcs, Apply for VIP
10 pcs, USD 230/pcs.
1 pcs, USD 250/pcs.
FOB ShenZhen

Add components to instrument
Weight: 1.5 kg/pcs
Delivery: within 1 weeks


Part Number (P/N) and Remark

100 pcs, Apply for VIP
10 pcs, USD 250/pcs.
1 pcs, USD 280/pcs.
FOB ShenZhen
